DK Photonics 515/532nm Picosecond Pulse Fiber Laser series ultrafast lasers utilizes high-performance rare earth fiber as the working medium, combined with fully polarization maintaining mode locking and frequency doubling technology, to achieve stable output of picosecond pulse laser in the 515 or 532nm wavelength band. It can fully self-start and work stably for a long time, with the characteristics of narrow laser pulses and high peak optical power. It can be used for scientific research in fields such as fluorescence lifetime microscopy imaging and nonlinear optics. Parameters such as wavelength, pulse width, power, and repetition rate can be specified or customized.
| Optical Parameter | Unit | Typical Values | Remark |
| Center wavelength | nm | 515/532 | Customizable |
| Spectral width | nm | 0.3 | Customizable |
| Pulse Width | ps | 10/20/50/100 | Customizable |
| Output average power | mW | 1~200 | Customizable |
| Power instability | – | < ±2% | @6hours |
| Repeat frequency | MHz | 15~80 | Customizable |
| Single pulse energy | nJ | >0.5 | |
| Stable locking time after startup | s | <20 | |
| Polarization state | Linear polarization | ||
| Laser output type | – | Free Space | |
| Preheat time | min | <1 |
| Electrical and environmental parameters | Desktop | Module |
| Control Mode | Touch screen | Touch screen |
| Synchronous electrical signal interface | SMA | SMA |
| Power Supply | 100~240V AC, <30W | 5V DC, <20W |
| Dimensions | 260(W)×280(D)×120(H)mm | 200(W)×121(D)×55(H)mm |
| Operation Temperature Range | 5~+45°C | |
| Operation Humidity Range | 0~70% | |
| ① | ② | ③ | ④ | ⑤ | ⑥ | ⑦ |
| PSPL | Wavelength | Pulse Width(fs) | Output average power (mW) | Repeat frequency | Output Type | Package Type |
| 515/532 | 10/20/50/100 | 10/50/200/
2000 |
15/50/100 | FS: Free-Space | M: Module
B: Desktop |
If you need to customize other specifications, please provide detailed description for your requirement.
